The Hoyer Classic HPL402 is a powered floor lift for homecare, rated 400 lb (181 kg). The boom is powered and the legs open by hand.
Who is it for, and who should choose something else?
- For a person up to 400 lb (181 kg) who needs a floor lift for bed, chair or floor transfers.
- For homecare, where the powered boom reduces the effort of lifting.
- A carer opens the base by hand with a pull handle; there is no motor on the legs.
- Choose a lighter lift if the 93 lb (42.2 kg) weight is hard to move between rooms.
Will it fit?
- Closed width is 24 in (610 mm), open width 39.5 in (1,003 mm), and overall length 44.8 in (1,137 mm).
- Check the narrowest doorway against the closed width, and measure the room.
- The lift weighs 93 lb (42.2 kg).
How does a transfer work?
- The boom runs from the hand control; the legs open by hand with a pull handle, right to widen and left to narrow.
- The actuator is reverse-mounted for knee clearance, and the base has leg guards and caster bumpers.
- The lift comes with a 4-point cradle. Use Hoyer 4-point slings only: never another maker's sling on this lift, and never a Hoyer sling on another maker's lift.
- Keep the base widened for stability, and never lock the brakes or block the wheels while lifting; the brakes are for parking.
Battery and charging
- Two 12 V sealed rechargeable batteries power the lift; the charger takes 120 V AC and outputs 24 V DC.
- A full charge takes about 6 hours, and an unused battery holds charge for about six months.
- Do not charge the battery while someone is in the lift or in a wet area.
What does the warranty cover?
Joerns covers the structure and power unit for 1 year; see the warranty terms.
How does it compare?
The Hoyer Advance is a lighter floor lift with a lower working load. See patient lifts and patient lift rentals.
Frequently asked questions
Does the base open with a motor?
No. The boom is powered; the base is manual. Pull the handle back to unlock, then move it right to widen or left to narrow.
Can it lower if the battery is flat?
Yes. A mechanical down-release lever lowers the boom without power, and the power unit has an emergency-down control.
What sling fits?
Hoyer 4-point slings on the lift's 4-point cradle. Do not use another maker's sling.
Is a scale included?
No. A scale is optional; ask if you need one before you order.
Funding and setup
Funding may help: see who may help pay. We deliver and set up floor lifts across Toronto and the GTA, fit the sling and show the emergency lowering. A free home assessment can check the doorway first.
Specifications
- Weight capacity
- 400 lb (181 kg)
- Product weight
- 93 lb (42.2 kg)
- Overall length
- 44.8 in (1,137 mm)
- Sling attachment
- 4-point cradle; Hoyer 4-point slings only
- Controls
- Hand control, single-speed actuator
- Emergency lowering
- Mechanical release, plus emergency down on the power unit
- Battery
- Two 12 V sealed rechargeable batteries
- Minimum lift height
- Boom 30.5 in (775 mm) at the lowest articulation
- Maximum lift height
- Boom 78 in (1,981 mm) at the highest articulation
- Base width closed
- 24 in (610 mm)
- Base width open
- 39.5 in (1,003 mm)
- Base widening
- Manual pull handle
- Battery charger
- 120 V AC input, 24 V DC output; full charge about 6 hours
- Warranty
- 1 year structure and power unit; 90 days batteries and casters; pendant 1 year
- Product type
- Powered floor lift
Figures from the manufacturer. Options and seat sizes can change them; we confirm yours before ordering.
Documents
Delivery and service
Delivery and setup
We deliver and set up equipment across Toronto and the GTA, and show you how everything works. Custom and special-order products can take longer; we confirm timing with you before delivery.
Service and repairs
Our technicians service what we sell, at home or in our shop.
Try before you buy
Visit a showroom in Etobicoke or Brampton to try products first, or book a free home assessment.
Warranty
Warranty details
Joerns Healthcare warrants Hoyer Classic lifts, including the HPL402, for one year after purchase by the original consumer or owner.
- Lifter structure (base, mast, boom and cradle), electronic control box and actuator: 1 year.
- Pendant: 1 year.
- Non-durable parts such as rubber and plastic parts, painted surfaces, batteries and casters: 90 days.
- Covers the original purchaser only, in Canada and the USA.
- Excludes damage from unsuitable environmental conditions or from maintenance that does not follow the user and service instructions.
- Any alteration, modification or repair not done or authorized in writing by Joerns Healthcare voids the warranty.
