Interstate

Interstate GEL0055 GEL Battery - 12 Volts 55AH

The Interstate GEL0055 is one 12 V sealed gel battery. It is 55 Ah, Group 22NF, with reversed terminals and an M6 insert. The case is 9.01 x 5.43 x 8.07 in and the weight is 35.49 lbs (16.10 kg). It is gel, not AGM. Sold one at a time. A 24 V chair that specifies gel in this group needs two, replaced together. An AGM 22NF does not replace it.

Key specifications All specifications
Battery voltage
12 V
Battery capacity
55 Ah
Battery group
Group 22NF, reversed terminals
Battery terminal
M6 insert (threaded)
Product weight
35.49 lbs (16.10 kg)
Sold as
One battery; most chairs use two
$ 345.44 $ 345.44

What is included?

One Interstate GEL0055 with an M6 insert. No charger, cables or second battery. To have it fitted and tested, use our battery replacement form.

Offers and rewards Applied in your cart at checkout.
  • Delivery and setup Across Toronto and the GTA: we set it up, show you how it works and service it at home or in our shop. Call (905) 798-1853
  • Safe checkout VISA Visa or Mastercard online, or pay in store when you visit us.
SKU
GEL0055
Brand
Interstate
Barcode GEL0055 GEL0055

Description

The Interstate GEL0055 is a 12 V sealed gel battery, Group 22NF with reversed terminals and an M6 insert. The price is for one battery.

Which power chairs and scooters does it fit?

Order it when the old battery is marked gel, 12 V, Group 22NF with reversed M6 inserts.

  • Pride Maxima 3-wheel: a 22NF gel pack. Match the old label before ordering.
  • Fortress 1700, 3-wheel and 4-wheel: Sunrise requires gel in that scooter, and the box maximum is 9.4 x 6.63 x 9.25 in. This case is 9.01 x 5.43 x 8.07 in; measure the inserts in the old battery.
  • Older Golden Avenger and Quantum Q6 Edge Z: their makers allow a gel NF-22, so check the label on the old pack.

Never mix gel with AGM. The DCM0055 is the AGM 22NF. The MK 8G22NF is MK's gel 22NF at a different rating.

What must match the old battery?

  • The chemistry: gel.
  • The terminal: reversed M6 inserts.
  • The case: 9.01 in long, 5.43 in wide and 8.07 in high (229 x 138 x 205 mm), plus the inserts.

How many do you need, and how are they charged?

Most 24 V chairs use two. Replace both at once; do not leave an old battery beside a new one. Charge with the chair's own charger on its gel setting.

Can you fly with it?

It is a sealed non-spillable gel battery under IATA and ICAO Special Provision A67. The airline must still approve the chair, so ask first.

What warranty comes with it?

The warranty is the manufacturer's or the store's, as stated on the sales order and invoice. It excludes deep discharge, storage in cold or heat, dirty contacts, non-approved chargers and misuse.

How do you recycle the old battery?

At 35.49 lbs (16.10 kg), this battery is over the 5 kg limit of Ontario's battery collection program. Never put it in the garbage or recycling. Take it to a Toronto household hazardous waste depot such as Disco Road, or a Peel Community Recycling Centre such as Brampton's on Chrysler Drive.

Funding may help: see who may help pay.

Frequently asked questions

Can I use this instead of an AGM 22NF?

Only if the chair maker allows gel. Do not mix one gel and one AGM in the same chair.

My old label says 50 Ah. Is this the same battery?

The GEL0055 is rated 55 Ah. Send us the label; do not assume 50 Ah and 55 Ah are the same part.

Will it fit a Fortress 1700?

Sunrise requires gel, and this case is inside the published box maximum. Measure the old battery, inserts included, before ordering.

Specifications

Product weight
35.49 lbs (16.10 kg)
Installation
Our technicians can fit and test it at your home or in our shop
Disposal
Lead acid over 5 kg: never in household garbage. Take it to a Toronto drop-off depot or a Peel Community Recycling Centre
Battery capacity
55 Ah
Battery voltage
12 V
Battery group
Group 22NF, reversed terminals
Battery terminal
M6 insert (threaded)
Sold as
One battery; most scooters and power chairs use two
Deep cycle
Yes. The case is marked pure gel deep cycle
Air travel
IATA and ICAO Special Provision A67 for non-spillable batteries; the airline must still approve the chair
Battery length
9.01 in (229 mm)
Battery width
5.43 in (138 mm)
Battery height
8.07 in (205 mm) case height
Compatible with
Pride Maxima 3-wheel; Fortress 1700 3- and 4-wheel (gel required); older Golden Avenger and Quantum Q6 Edge Z (gel NF-22). Match the gel label and M6 terminals.
Battery charger
Charges on the scooter or power chair's own charger
Product type
Power wheelchair and scooter battery
Chemistry
Sealed lead acid, gel electrolyte, valve regulated

Options and sizes can change some figures. Ask us to confirm yours before you order.
