Carina350EE floor lift, low legs, item 60600014

Parts finder

Replacement parts for the Carina350EE floor lift, low legs, item 60600014

The exploded view is numbered. Select a number on the drawing to jump to that part, or search the list. Prices shown are current online prices; anything without a price is quoted for you.

Ask about a part Product page 59 parts listed Model 60600014

Showing all 59 parts

1 of 4
Exploded view of the Mast and boom
Mast and boom. Numbers match the list.
Lifting arm. Numbers match the list.
Right leg, low legs. Numbers match the list.
Base, Carina350EE with low legs. Numbers match the list.

Mast and boom

19 parts

Exploded view from the Handicare Carina350EM/EE service manual, manual nr 882 En Ver. 4, page 5. The numbers on the drawing match this list.

Parts in Mast and boom
No.PartQtyPriceAction
1 Carina mast completeManufacturer no. 90000472_6 1Quote Ask us about this part
2 Lifting arm completeManufacturer no. 90000476_5 1Quote Ask us about this part
3 LA31-J07934Manufacturer no. 90003163 1Quote Ask us about this part
4 Link VManufacturer no. 90000731 1Quote Ask us about this part
5 Screw M6S DIN931 8.8 M8x65 fzbManufacturer no. 90000028 1Quote Ask us about this part
6 Nut cover MSM8GManufacturer no. 90000330 4Quote Ask us about this part
7 Lock nut DIN985 M8 fzbManufacturer no. 90000026 2Quote Ask us about this part
8 Sleeve 10x8x50Manufacturer no. 90000459 1Quote Ask us about this part
9 Sleeve 10x8x26Manufacturer no. 90000453 1Quote Ask us about this part
10 Washer DIN125 8.4x16x1.6 fzbManufacturer no. 90000345 2Quote Ask us about this part
11 M6S DIN 931 8.8 M8x40 fzbManufacturer no. 90000488 1Quote Ask us about this part
12 Locking Pin D10 3332.W102Manufacturer no. 90000492 1Quote Ask us about this part
13 Nut cover MSM12GManufacturer no. 90000493 2Quote Ask us about this part
14 Lock nut DIN985 CL6 M12 fzbManufacturer no. 90000487 1Quote Ask us about this part
15 Washer BRB 13x24x2.5 fzbManufacturer no. 90003131 2Quote Ask us about this part
16 Screw M6S DIN931 M12x95Manufacturer no. 90003129 1Quote Ask us about this part
17 Sleeve 16,1x12,1x71,5Manufacturer no. 90003130 1Quote Ask us about this part
18 Shim_50x17x2Manufacturer no. 90003118 2Quote Ask us about this part
19 Bushing teflon C0B010-1012Manufacturer no. 90000732 1Quote Ask us about this part

Lifting arm

4 parts

Exploded view from the Handicare Carina350EM/EE service manual, manual nr 882 En Ver. 4, page 6. The numbers on the drawing match this list.

Parts in Lifting arm
No.PartQtyPriceAction
1 Lifting arm weldedManufacturer no. 90000476 1Quote Ask us about this part
2 End plug armManufacturer no. 90000475 1Quote Ask us about this part
3 Bushing lifting armManufacturer no. 90002774 1Quote Ask us about this part
4 Screw RXS DIN7981-C-H 4.8 4,2x16 fzbManufacturer no. 90002733 2Quote Ask us about this part

Right leg, low legs

12 parts

Exploded view from the Handicare Carina350EM/EE service manual, manual nr 882 En Ver. 4, page 8. The numbers on the drawing match this list.

Parts in Right leg, low legs
No.PartQtyPriceAction
1 Carina low leg right weldedManufacturer no. 90002573 1Quote Ask us about this part
2 Bushing teflon C0B010f-16170Manufacturer no. 90000479 2Quote Ask us about this part
3 Rear fork 125 mmManufacturer no. 90002578 1Quote Ask us about this part
4 Screw_K6S_ISO7380_10.9_M8x25_fzbManufacturer no. 90002435 1Quote Ask us about this part
5 Screw MF6S DIN7991 8.8 M10x90 fzbManufacturer no. 90001993 1Quote Ask us about this part
6 Wheel bumperManufacturer no. 90003460 1Quote Ask us about this part
7 Rear wheel 100mmManufacturer no. 90000260 1Quote Ask us about this part
8 Lock nut DIN 985 CL6 M10 FZBManufacturer no. 90000539 1Quote Ask us about this part
9 Screw MF6S DIN7991 8,8 M6x25 fzbManufacturer no. 90000422 2Quote Ask us about this part
10 Wheel Blickle LRA-VSTH 35KManufacturer no. 90001650 2Quote Ask us about this part
11 Washer BN732 6.4x20x1.5 fzbManufacturer no. 90000423 2Quote Ask us about this part
12 Lock nut DIN985 M6 fzbManufacturer no. 90000155 2Quote Ask us about this part

Base, Carina350EE with low legs

22 parts

Exploded view from the Handicare Carina350EM/EE service manual, manual nr 882 En Ver. 4, page 9. The numbers on the drawing match this list.

Parts in Base, Carina350EE with low legs
No.PartQtyPriceAction
1 Carina center sectionManufacturer no. 90000469 1Quote Ask us about this part
2 Carina low leg right asmManufacturer no. 90002574 1Quote Ask us about this part
3 Carina low leg left asmManufacturer no. 90002581 1Quote Ask us about this part
4 Shoulder bolt ISO7379 (DIN610) 12.9 16xM12x60Manufacturer no. 90000485 2Quote Ask us about this part
5 Washer DIN125 13x25x2.5 fzbManufacturer no. 90000486 2Quote Ask us about this part
6 Lock nut DIN985 CL6 M12 fzbManufacturer no. 90000487 2Quote Ask us about this part
7 Locking handle LSS64M10SManufacturer no. 90000329 2Quote Ask us about this part
8 Washer DIN125 10.5x20x2 fzbManufacturer no. 90000601 2Quote Ask us about this part
9 Threaded rod DIN976 M10x80 FZBManufacturer no. 90002951 1Quote Ask us about this part
10 Plastic protection CarinaManufacturer no. 90000647 1Quote Ask us about this part
11 Shoulder bolt cover M12 GManufacturer no. 90000778 2Quote Ask us about this part
12 Bracket actuator centerManufacturer no. 90000458 1Quote Ask us about this part
13 Leg spread actuator LA23-230006-02Manufacturer no. 90001146 1Quote Ask us about this part
14 M6S DIN 931 8.8 M8x40 fzbManufacturer no. 90000488 2Quote Ask us about this part
15 Washer DIN125 8.4x16x1.6 fzbManufacturer no. 90000345 4Quote Ask us about this part
16 Sleeve 10x8x26Manufacturer no. 90000453 2Quote Ask us about this part
17 Lock nut DIN985 M8 fzbManufacturer no. 90000026 2Quote Ask us about this part
18 Nut cover MSM8GManufacturer no. 90000330 4Quote Ask us about this part
19 Screw K6S DIN7380 8.8 M8x20 fzbManufacturer no. 90000467 4Quote Ask us about this part
20 Watt linkManufacturer no. 90000464_5 1Quote Ask us about this part
21 Strut leg spread "#2"Manufacturer no. 90000460 2Quote Ask us about this part
22 Cable leg spread actuator 0237054-0750-BManufacturer no. 90001604 1Quote Ask us about this part

Control box

1 part
Parts in Control box
No.PartQtyPriceAction
Handicare Replacement Lift Battery 280124280124 1$192.20 Add to cart

Other parts

1 part
Parts in Other parts
No.PartQtyPriceAction
Handicare Carina350EM/EE Locking Handles 8010006780100067 1$139.51 Add to cart

Not sure which part you need?

Send us a photo of the part, or of where it sits, and tell us what it is doing: the Request a repair form takes a photo. Or describe it below and we will identify it. We would rather ask you one question than send you the wrong part.

Or call (905) 798-1853 and describe it to us.
