Beka CARLO Alu Classic 924002508, the low-leg floor lift

The Beka CARLO Alu Classic 924002508 is the low-leg aluminum floor lift for a person who needs a full lift in a loop sling. The legs spread under power. Safe working load is 407.86 lb (185 kg).

Key specifications All specifications
Weight capacity
407.86 lb (185 kg)
Item number
924002508
Base width closed
27.56 in (700 mm)
Leg opening
40.94 in (1,040 mm) inside, legs spread
Sling attachment
6-point carry bar for loop slings
Base height
4.92 in (125 mm) Classic frame, confirm the low-leg chassis
$ 11,860.04 $ 11,860.04

What is included?

The low-leg lift, 6-point loop bar, cable hand control and on-board charger. A sling and a scale are separate. Tell us the bed so we can check the legs.

Offers and rewards Applied in your cart at checkout.
  • Delivery and setup Across Toronto and the GTA: we set it up, show you how it works and service it at home or in our shop. Call (905) 798-1853
  • Safe checkout VISA Visa or Mastercard online, or pay in store when you visit us.
SKU
924002508
Brand
Handicare
Category
Patient Lifts
Barcode 924002508 924002508

Complete your equipment setup

Description

The Beka CARLO Alu Classic 924002508 is the low-leg floor lift for a loop-sling transfer, up to 407.86 lb (185 kg).

What does it do and how does it work?

  • Aluminum mast, column and base. The 6-point bar takes loop slings, lowers to the floor, and does not spin unless you turn it.
  • A cable hand control raises the bar and spreads the legs. Control-unit buttons do the same if the hand control fails and the battery still has charge.
  • Slide the red lock up and the motor lowers about 44 lb (20 kg). Release it and the motor stops.
  • The emergency stop cuts power. Turn it clockwise to release. This Canadian unit charges only with the stop released.
  • 24 V lead-acid battery, 2.9 Ah. On-board charge from 100-240 V takes about 4 hours. Do not lift while it charges. Run 2 minutes, then rest 18 minutes. An orange light means 185 kg is exceeded. Four double 3.9 in (100 mm) casters, rear pair locking. Rated IPX4.

Who is it for, and who should choose something else?

  • Someone who needs a full lift in a loop sling, up to 407.86 lb (185 kg).
  • A low bed, stretcher or furniture a standard Classic frame may not clear.
  • Over 407.86 lb, choose a 230 kg Classic. For clip slings and a powered tilt bar, choose the CARLO Comfort EP.
  • Ask the physician first for osteoporosis, a spine injury, osteogenesis imperfecta, confusion or seizures.

Will it fit?

  • Closed base: 27.56 in (700 mm) outside, 21.26 in (540 mm) inside. Measure the narrowest door.
  • Spread base: 46.46 in (1,180 mm) outside, 40.94 in (1,040 mm) inside, around a chair or commode.
  • Classic frame height is 4.92 in (125 mm). We confirm 924002508 clears the space under the bed before you order.
  • Overall height 52.8-85.4 in (1,340-2,170 mm). Turning radius 53.1 in (135 cm). Hanger-bar height is 7.87-62.2 in (20.0-158.0 cm), indoors on a level floor.

Using it day to day

  • Charge fully before the first lift, and recharge a stored battery every 6 months. Lock the rear casters before you lift. Clean it only while it is off and unplugged.

What does it work with, and what are its limits?

  • Loop slings only. See patient lift slings. The scale is a separate kit.
  • It lifts from a bed, a chair or the floor, then moves a short way in the same room. It is not a hallway transporter.
  • More patient lifts. A short need can start with a patient lift rental.

How does it compare?

  • The CARLO Classic 924003208 is the same 185 kg loop-sling lift without the low-leg code.
  • The Hoyer Advance is the smaller electric floor lift when this frame is more than the room needs.

Frequently asked questions

Can I lift someone while the battery is charging?

No. Unplug it first. A charge from empty takes about 4 hours.

What if the hand control fails halfway up?

Use the buttons on the control unit if the battery still has charge. The red lock lowers the bar on its own, about 44 lb (20 kg).

Is a sling in the box?

No. Order a loop sling in the person's size. Clip slings do not fit.

Can I wheel the person down the hall?

Only a short move on a smooth level floor in the same room.

Funding may help: see who may help pay.

Specifications

Weight capacity
407.86 lb (185 kg)
Product weight
121-143 lb (55-65 kg) without packaging
Caster size
3.9 in (100 mm) double casters, rear pair with brakes
Overall height
52.8-85.4 in (1,340-2,170 mm)
Overall length
50.78 in (1,290 mm) carrier frame
Sling attachment
6-point carry bar for loop slings
Lifts from floor
Yes, carry bar lowers to the floor
Controls
Cable hand control, plus buttons on the control unit
Emergency lowering
Manual red lock, and electrical buttons on the control unit
Battery
24 V lead-acid, 2.9 Ah
Water resistance
IPX4
Minimum lift height
7.87 in (20.0 cm) at the hanger bar
Maximum lift height
62.2 in (158.0 cm) at the hanger bar
Base width closed
27.56 in (700 mm)
Base width open
46.46 in (1,180 mm)
Base height
4.92 in (125 mm) Classic carrier frame
Base widening
Powered, from the cable hand control
Leg opening
40.94 in (1,040 mm) inside, legs spread
Material
Aluminum mast, column and base
Compatible with
Loop slings
Battery charger
On-board, 100-240 V AC in, 24 V DC out, about 4 hours
Product type
Electric floor lift

Options and sizes can change some figures. Ask us to confirm yours before you order.
